It appears you are looking for a specific type of industrial fan used in high-temperature applications. Based on your keywords, you are describing a Large Capacity, Heavy-Duty Centrifugal Fan with Backward Curved (or Backward Inclined) Blades, designed for Cement Kilns or Kiln Cooling systems (likely for Clinker Coolers or Grate Coolers).
Here is a technical breakdown and key information regarding these critical components.
Why "Backward Curved" for Kilns & Cooling?
Backward Curved (BC) or Backward Inclined (BI) blades are the industry standard for heavy-duty cement kiln applications for three main reasons:
- High Efficiency: BC blades are the most energy-efficient centrifugal fan design (up to 85-90% static efficiency). Since kiln cooling fans run 24/7, this efficiency is crucial for operational costs.
- Non-Overloading Power Curve: This is critical for motor protection. If the system pressure drops (e.g., a filter bag breaks or a duct opens), a BC fan's power draw does not spike (unlike forward-curved fans). The motor will not overload.
- Handling Dust: In a kiln cooling context (clinker cooler), the air is laden with hot, abrasive dust. A robust backward curved fan with a heavy-duty wheel handles this erosion better than other types.
The Application: Kiln Cooling
The term "Kilns Cooling" usually refers to the Clinker Cooler Ventilation Fan (Grate Cooler) . This fan pulls ambient air through the red-hot clinker to rapidly cool it from ~1400°C to ~100°C.
Fan Requirements:
- High Volume (Large Capacity): A single clinker cooler for a 5,000 ton/day kiln can require a fan delivering over 800,000 m³/h (470,000 CFM) .
- High Pressure (Heavy Duty): Static pressure typically ranges from 4,000 to 8,000 Pa (16" to 32" w.g.) depending on the cooler design (Reciprocating grate vs. Delta/Cross-bar cooler).
- Temperature: Inlet temperatures are usually 150°C to 350°C (even up to 450°C in some undergrate conditions). The fan requires a special shaft sealing and expansion allowance to prevent thermal distortion.
Critical Design Features (Heavy Duty)
| Feature | Why it matters for Kiln Cooling |
|---|---|
| Wheel Material | Corten Steel (Weathering) or Hardox / Abrasion Resistant (AR) steel for the blades and backplate. |
| Thick Blade Profile | Blades are often 10-16 mm thick. Leading edges are welded with hard-facing or ceramic tiles to resist erosion. |
| Shaft & Hub | Oversized shaft with a cooling disc (or heat slinger) between the bearing and the housing to prevent heat transfer. |
| Bearing Arrangement | Air-cooled pillow block bearings or water-cooled bearing assemblies. Heavy-duty spherical roller bearings (SKF/FAG) rated for a B-10 life > 100,000 hours. |
| Housing | Split housing (for maintenance) made of 10-20 mm plate steel with robust external stiffening ribs. |
| Variable Speed Drive | Almost always driven by a VFD (Variable Frequency Drive) to control airflow for cooling zones and kiln draft. |
Typical Specifications (for a mid-to-large cement plant)
- Type: Single Inlet, Single Width (SISW) or Double Inlet (DIDW) Backward Curved Centrifugal Fan.
- Drive Arrangement: Arrangement 3 (Belt driven) or Arrangement 7 (Direct driven with VFD).
- Max Efficiency: 85%+
- Noise Levels: Requires an acoustic enclosure or silencer to meet OSHA / local noise regulations.
- Standards: Manufactured to AMCA (Air Movement and Control Association) standards for sound and performance testing.
Common Manufacturers for this specific profile
If you are sourcing this fan, look for companies with a dedicated Cement Division:
- Howden (Roots/Clair) - Very common in Cement kilns.
- Greenheck (Industrial Division) - For smaller operations.
- Cincinnati Fan / New York Blower - (Industrial heavy-duty lines).
- TLT-Turbo / Siemens Process Instruments - (High-end European spec).
- Robinson Fans - "The Big Fans" for severe duty.
- Zibo FOVO / Shenyang Blower - (Proven Chinese manufacturers for large capacity units).
Customer Question / Next Step: Are you looking to replace an existing fan (e.g., "Howden Model X") or are you designing a new kiln line and need a Request For Quotation (RFQ) specification?
(If you can provide the air volume (CFM/m³/h) , static pressure (Pa/InWG) , and gas temperature at the fan inlet, I can help calculate the required motor power and fan speed.)
